Product Description
Hot sales En124 D400 Cast Iron Manhole Covers / Rectangular Manhole Cover / Ductile Iron Manhole Covers / Sewer Manhole Cover
Ductile iron manhole cover is made from spheroidal graphite cast iron by machining hand moulding, solid top, recessed,double triangular, single seal or double seal, square or rectangular or round,with or without hinge. Very good quality, smooth and free from sand holes, blow holes, distortion or any other defects. Loading capacity is 40 tons. The normal coating is black bitumen 30 microns thickness, also can make the epoxy coating according to the customer's demand.
Clear opening size is as below:
| Class D400 specifications | |||||
| Type | Dimensions (mm) | H | e | ||
| | A X A | O X O | C X C | | |
| Single Sealed, Square | 600X600 | 500X500 | 532X532 | 100 | 50 |
| Single Sealed, Square | 700X700 | 600X600 | 633X633 | 100 | 50 |
| Single Sealed, Square | 800X800 | 700X700 | 733X733 | 100 | 50 |
| Single Sealed, Square | 900X900 | 800X800 | 833X833 | 100 | 50 |
| Single Sealed, Square | 1000X1000 | 900X900 | 933X933 | 100 | 50 |
| Single Sealed, Square | 1100X1100 | 1000X1000 | 1033X1033 | 100 | 50 |
| Single Sealed, Square | 1200X1200 | 1100X1000 | 1133X1133 | 100 | 51 |
| Single Sealed, Rectangular | 600X800 | 500X700 | 558X762 | 80 | 72 |
| Single Sealed, Rectangular | 750X550 | 600X450 | 636X486 | 75 | 69 |
| Single Sealed, Round cover, Round Base | Ф850 | Ф600 | Ф646 | 95 | 49 |
| Single Sealed, Round cover, Rectangular Base | 850X850 | Ф600 | Ф645 | 100 | 49 |
| Single Sealed, Round cover, Rectangular Base | 700X700 | Ф600 | Ф645 | 100 | 49 |
| Single Sealed, Round cover, Rectangular Base | 900X900 | Ф710 | Ф734 | 102 | 41 |
| Single Sealed, Round cover, Rectangular Base | 1000X1000 | Ф710 | Ф734 | 102 | 41 |
| Single Sealed, Round cover, Rectangular Base | 1050X1050 | Ф850 | Ф835 | 100 | 46 |
| Single Sealed, Round cover, Round Base | Ø750 | Ø600 | Ø660 | 100 | 29 |
| Single Sealed, Round cover, Round Base | Ø780 | Ø600 | Ø660 | 100 | 29 |
| Double Sealed, Square, Recessed Cover | 750X750 | 600X600 | 694X694 | 100 | 29 |
| Double Sealed, Square, Solid Top | 750X750 | 600X600 | 694X694 | 100 | 29 |
Manhole Cover Series (EN 124) - Maximum load allowed for various classes
CLICK THE PICTURES AS BELOW TO KNOW MORE ABOUT OUR PRODUCTS
1.Packing Details : carton+plywood pallets/cases+container.
3. According to the customer's requirement.
4.Delivery Details : 15-30 days after confirming order.
